STTH30L06CG
RoHS
RoHS compliant
RoHS compliantPackage TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY GP 600V 20A D2PAK
PDF
/
Buying Options
Total Price: USD $9.39
Unit Price: USD $9.38695
≥1 USD $9.38695
≥10 USD $7.7026
≥100 USD $7.46225
≥500 USD $7.22095
≥1000 USD $6.9806
Inventory: 1371
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Diode Element Material SILICON
Technical
Packaging Tube
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Max Operating Temperature 175°C
Min Operating Temperature -65°C
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Voltage - Rated DC 600V
Terminal Position SINGLE
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 245
Reach Compliance Code not_compliant
Current Rating 40A
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number STTH30
Pin Count 3
JESD-30 Code R-PSSO-G2
Qualification Status Not Qualified
Number of Elements 2
Element Configuration Common Cathode
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 15μA @ 600V
Voltage - Forward (Vf) (Max) @ If 1.55V @ 15A
Operating Temperature - Junction 175°C Max
Max Surge Current 130A
Application HIGH VOLTAGE ULTRA FAST RECOVERY
Max Reverse Voltage (DC) 600V
Average Rectified Current 20A
Number of Phases 1
Reverse Recovery Time 85 ns
Peak Reverse Current 15μA
Reverse Voltage 600V
Diode Configuration 1 Pair Common Cathode
Recovery Time 85 ns
Compliance
RoHS Status ROHS3 Compliant
