STTH3002CR
RoHS
/
Package TO-262-3 Long Leads, I2Pak, TO-262AA
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY GP 200V 15A I2PAK
PDF
/
Buying Options
Total Price: USD $2.36
Unit Price: USD $2.3584
≥1 USD $2.3584
≥10 USD $1.95976
≥100 USD $1.559888
≥500 USD $1.319859
≥1000 USD $1.119888
Inventory: 1778
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
Recovery Time 22 ns
Diode Configuration 1 Pair Common Cathode
Reverse Voltage 200V
Peak Reverse Current 20μA
Reverse Recovery Time 22 ns
Number of Phases 1
Average Rectified Current 15A
Max Reverse Voltage (DC) 200V
Application EFFICIENCY
Max Surge Current 180A
Operating Temperature - Junction 175°C Max
Case Connection ISOLATED
Voltage - Forward (Vf) (Max) @ If 1.05V @ 15A
Current - Reverse Leakage @ Vr 20μA @ 200V
Diode Type Standard
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Common Cathode
Number of Elements 2
Qualification Status Not Qualified
JESD-30 Code R-PSIP-T3
Pin Count 3
Base Part Number STTH30
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Current Rating 30A
Reach Compliance Code not_compliant
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Voltage - Rated DC 200V
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
Additional Feature FREE WHEELING DIODE
Min Operating Temperature -65°C
Max Operating Temperature 175°C
Terminal Finish Tin (Sn)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Packaging Tube
Physical
Diode Element Material SILICON
Package / Case TO-262-3 Long Leads, I2Pak, TO-262AA
Mounting Type Through Hole
Mount Through Hole
