STTH3002CG-TR
RoHS
RoHS compliant
RoHS compliantPackage TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY GP 200V 15A D2PAK
PDF
/
Buying Options
Total Price: USD $2.01
Unit Price: USD $2.0064
≥1 USD $2.0064
≥10 USD $1.6632
≥100 USD $1.32396
≥500 USD $1.120275
Inventory: 6394
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Number of Pins 3
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Max Operating Temperature 175°C
Min Operating Temperature -65°C
Additional Feature FREE WHEELING DIODE
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Voltage - Rated DC 200V
Terminal Position SINGLE
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 245
Current Rating 30A
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number STTH30
Pin Count 3
JESD-30 Code R-PSSO-G2
Number of Elements 2
Element Configuration Common Cathode
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 20μA @ 200V
Voltage - Forward (Vf) (Max) @ If 1.05V @ 15A
Forward Current 30A
Operating Temperature - Junction 175°C Max
Max Surge Current 180A
Application EFFICIENCY
Forward Voltage 1.18V
Max Reverse Voltage (DC) 200V
Average Rectified Current 15A
Number of Phases 1
Reverse Recovery Time 22 ns
Peak Reverse Current 20μA
Max Repetitive Reverse Voltage (Vrrm) 200V
Peak Non-Repetitive Surge Current 180A
Reverse Voltage 200V
Diode Configuration 1 Pair Common Cathode
Recovery Time 22 ns
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
