STTH20L03CT
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY GP 300V 10A TO220AB
PDF
/
Buying Options
Total Price: USD $1.4
Unit Price: USD $1.3992
≥1 USD $1.3992
≥10 USD $1.120592
≥100 USD $0.922064
≥500 USD $0.78019
≥1000 USD $0.66198
≥3000 USD $0.628883
Inventory: 1065
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-3
Number of Pins 3
Diode Element Material SILICON
Technical
Packaging Tube
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Max Operating Temperature 175°C
Min Operating Temperature -40°C
Terminal Position SINGLE
Base Part Number STTH2
Number of Elements 2
Element Configuration Common Cathode
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 10μA @ 300V
Voltage - Forward (Vf) (Max) @ If 1.2V @ 10A
Forward Current 20A
Operating Temperature - Junction -40°C~175°C
Application ULTRA FAST SOFT RECOVERY
Max Reverse Voltage (DC) 300V
Average Rectified Current 10A
Number of Phases 1
Reverse Recovery Time 26 ns
Peak Reverse Current 100μA
Max Repetitive Reverse Voltage (Vrrm) 300V
JEDEC-95 Code TO-220AB
Peak Non-Repetitive Surge Current 150A
Reverse Voltage 300V
Diode Configuration 1 Pair Common Cathode
Recovery Time 200 ns
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
