STTH2003CT
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY GP 300V 10A TO220AB
PDF
/
Buying Options
Total Price: USD $0.61
Unit Price: USD $0.61104
≥1 USD $0.61104
≥10 USD $0.57645
≥100 USD $0.54382
≥500 USD $0.51304
≥1000 USD $0.484
≥3000 USD $0.4566
Inventory: 291425
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 4.6mm
Length 10.4mm
Height 15.75mm
Technical
Recovery Time 35 ns
Max Forward Surge Current (Ifsm) 110A
Diode Configuration 1 Pair Common Cathode
Reverse Voltage 300V
Peak Non-Repetitive Surge Current 110A
JEDEC-95 Code TO-220AB
Max Repetitive Reverse Voltage (Vrrm) 300V
Peak Reverse Current 20μA
Reverse Recovery Time 35 ns
Number of Phases 1
Average Rectified Current 10A
Max Reverse Voltage (DC) 300V
Forward Voltage 1.25V
Application ULTRA FAST SOFT RECOVERY
Max Surge Current 110A
Operating Temperature - Junction 175°C Max
Forward Current 20A
Voltage - Forward (Vf) (Max) @ If 1.25V @ 10A
Current - Reverse Leakage @ Vr 20μA @ 300V
Diode Type Standard
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Common Cathode
Number of Elements 2
Pin Count 3
Base Part Number STTH2
Current Rating 20A
Terminal Position SINGLE
Voltage - Rated DC 300V
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
Min Operating Temperature -65°C
Max Operating Temperature 175°C
Terminal Finish Tin (Sn)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Packaging Tube
Physical
Diode Element Material SILICON
Weight 4.535924g
Number of Pins 3
Package / Case TO-220-3
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 months ago)
Factory Lead Time 11 Weeks
