STTH2003CG
RoHS
RoHS compliant
RoHS compliantPackage TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY GP 300V 10A D2PAK
PDF
/
Buying Options
Total Price: USD $1.75
Unit Price: USD $1.74515
≥1 USD $1.74515
≥10 USD $1.4326
≥100 USD $1.38795
≥500 USD $1.34235
≥1000 USD $1.2977
Inventory: 1443
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Number of Pins 3
Diode Element Material SILICON
Technical
Packaging Tube
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Max Operating Temperature 175°C
Min Operating Temperature -65°C
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Voltage - Rated DC 300V
Terminal Position SINGLE
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 245
Reach Compliance Code not_compliant
Current Rating 20A
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number STTH2
Pin Count 3
JESD-30 Code R-PSSO-G2
Qualification Status Not Qualified
Number of Elements 2
Element Configuration Common Cathode
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 20μA @ 300V
Voltage - Forward (Vf) (Max) @ If 1.25V @ 10A
Forward Current 20A
Operating Temperature - Junction 175°C Max
Max Surge Current 110A
Application ULTRA FAST SOFT RECOVERY
Forward Voltage 1.25V
Max Reverse Voltage (DC) 300V
Average Rectified Current 10A
Number of Phases 1
Reverse Recovery Time 35 ns
Peak Reverse Current 20μA
Max Repetitive Reverse Voltage (Vrrm) 300V
Peak Non-Repetitive Surge Current 110A
Reverse Voltage 300V
Diode Configuration 1 Pair Common Cathode
Max Forward Surge Current (Ifsm) 110A
Recovery Time 35 ns
Dimensions
Height 4.6mm
Length 10.28mm
Width 9.35mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
