STTH2003CFP
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3 Full Pack
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
STTH2003 Series 10 A 1 V Flange Mount Ultrafast Secondary Rectifier - TO-220FP
PDF
/
Buying Options
Total Price: USD $1.62
Unit Price: USD $1.6192
≥1 USD $1.6192
≥10 USD $1.298
≥100 USD $1.067968
≥500 USD $0.903672
≥1000 USD $0.766753
≥3000 USD $0.728411
Inventory: 55139
Minimum: 1
-
+
Technical Details
Technical
Case Connection ISOLATED
Voltage - Forward (Vf) (Max) @ If 1.25V @ 10A
Current - Reverse Leakage @ Vr 20μA @ 300V
Diode Type Standard
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Common Cathode
Number of Elements 2
Pin Count 3
Base Part Number STTH2
Current Rating 10A
Terminal Position SINGLE
Voltage - Rated DC 300V
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
Min Operating Temperature -65°C
Max Operating Temperature 175°C
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Packaging Tube
Recovery Time 35 ns
Max Forward Surge Current (Ifsm) 110A
Diode Configuration 1 Pair Common Cathode
Reverse Voltage 300V
Peak Non-Repetitive Surge Current 110A
JEDEC-95 Code TO-220AB
Max Repetitive Reverse Voltage (Vrrm) 300V
Peak Reverse Current 20μA
Reverse Recovery Time 35 ns
Number of Phases 1
Average Rectified Current 10A
Max Reverse Voltage (DC) 300V
Forward Voltage 1.25V
Application ULTRA FAST SOFT RECOVERY
Max Surge Current 110A
Operating Temperature - Junction 175°C Max
Forward Current 20A
Physical
Diode Element Material SILICON
Number of Pins 3
Package / Case TO-220-3 Full Pack
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 15 Weeks
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 4.9mm
Length 10.7mm
Height 16.4mm
