STTH16R04CT
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY GP 400V 8A TO220AB
PDF
/
Buying Options
Total Price: USD $0.92
Unit Price: USD $0.924
≥1 USD $0.924
≥10 USD $0.741312
≥100 USD $0.609928
≥500 USD $0.550669
Inventory: 335
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 4.6mm
Length 10.4mm
Height 15.9mm
Technical
Recovery Time 50 ns
Max Forward Surge Current (Ifsm) 120A
Diode Configuration 1 Pair Common Cathode
Reverse Voltage 400V
Peak Non-Repetitive Surge Current 120A
JEDEC-95 Code TO-220AB
Max Repetitive Reverse Voltage (Vrrm) 400V
Peak Reverse Current 10μA
Reverse Recovery Time 50 ns
Number of Phases 1
Average Rectified Current 8A
Max Reverse Voltage (DC) 400V
Forward Voltage 1.75V
Application ULTRA FAST RECOVERY
Output Current-Max 8A
Max Surge Current 120A
Operating Temperature - Junction -40°C~175°C
Forward Current 16A
Voltage - Forward (Vf) (Max) @ If 1.5V @ 8A
Current - Reverse Leakage @ Vr 10μA @ 400V
Diode Type Standard
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Common Cathode
Number of Elements 2
Pin Count 3
Base Part Number STTH16
Peak Reflow Temperature (Cel) 225
Terminal Position SINGLE
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
Additional Feature FREE WHEELING DIODE, SOFT FACTOR IS 0.4
Min Operating Temperature -40°C
Max Operating Temperature 175°C
Terminal Finish MATTE TIN
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Packaging Tube
Physical
Diode Element Material SILICON
Number of Pins 3
Package / Case TO-220-3
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 11 Weeks
