STTH15AC06CFP
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3 Full Pack
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
Rectifiers Ultrafast Recovery 1500V 12pF Diode
PDF
/
Buying Options
Total Price: USD $1.14
Unit Price: USD $1.1352
≥1 USD $1.1352
≥10 USD $0.910096
≥100 USD $0.721248
Inventory: 455
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-3 Full Pack
Number of Pins 3
Diode Element Material SILICON
Technical
Packaging Tube
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Max Operating Temperature 175°C
Min Operating Temperature -65°C
Additional Feature FREE WHEELING DIODE
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number STTH15
Number of Elements 2
Element Configuration Common Cathode
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 1μA @ 600V
Voltage - Forward (Vf) (Max) @ If 1.9V @ 7.5A
Forward Current 15A
Operating Temperature - Junction -65°C~175°C
Max Surge Current 80A
Application HIGH VOLTAGE ULTRA FAST RECOVERY
Forward Voltage 2.2V
Max Reverse Voltage (DC) 600V
Average Rectified Current 7.5A
Number of Phases 1
Reverse Recovery Time 50 ns
Peak Reverse Current 10μA
Max Repetitive Reverse Voltage (Vrrm) 600V
JEDEC-95 Code TO-220AB
Peak Non-Repetitive Surge Current 80A
Reverse Voltage 600V
Diode Configuration 1 Pair Common Cathode
Max Forward Surge Current (Ifsm) 80A
Recovery Time 35 ns
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
