STTH10LCD06CT
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY GP 600V 5A TO220AB
PDF
/
Buying Options
Total Price: USD $0.54
Unit Price: USD $0.5377
≥1 USD $0.5377
≥10 USD $0.4408
≥100 USD $0.4275
≥500 USD $0.41325
≥1000 USD $0.39995
≥1000 USD $0.35815
Inventory: 230
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-3
Number of Pins 3
Diode Element Material SILICON
Technical
Packaging Tube
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Max Operating Temperature 175°C
Min Operating Temperature -65°C
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Terminal Position SINGLE
Base Part Number STTH10
Pin Count 3
Number of Elements 2
Element Configuration Common Cathode
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 1μA @ 600V
Voltage - Forward (Vf) (Max) @ If 2V @ 5A
Forward Current 10A
Operating Temperature - Junction 175°C Max
Max Surge Current 45A
Output Current-Max 5A
Application HIGH VOLTAGE ULTRA FAST RECOVERY
Forward Voltage 2.35V
Max Reverse Voltage (DC) 600V
Average Rectified Current 5A
Number of Phases 1
Reverse Recovery Time 50 ns
Peak Reverse Current 1μA
Max Repetitive Reverse Voltage (Vrrm) 600V
JEDEC-95 Code TO-220AB
Peak Non-Repetitive Surge Current 60A
Reverse Voltage 600V
Diode Configuration 1 Pair Common Cathode
Recovery Time 100 ns
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
