STTH1002CG-TR
RoHS
RoHS compliant
RoHS compliantPackage TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY GP 200V 8A D2PAK
PDF
/
Buying Options
Total Price: USD $1.06
Unit Price: USD $1.0648
≥1 USD $1.0648
≥10 USD $0.8712
≥100 USD $0.677512
≥500 USD $0.574288
Inventory: 720
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Number of Pins 3
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Max Operating Temperature 175°C
Min Operating Temperature -65°C
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Voltage - Rated DC 200V
Terminal Position SINGLE
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 245
Current Rating 16A
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number STTH10
Pin Count 3
JESD-30 Code R-PSSO-G2
Number of Elements 2
Element Configuration Common Cathode
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 5μA @ 200V
Voltage - Forward (Vf) (Max) @ If 1.1V @ 5A
Forward Current 10A
Operating Temperature - Junction 175°C Max
Max Surge Current 50A
Output Current-Max 8A
Application EFFICIENCY
Forward Voltage 1.25V
Max Reverse Voltage (DC) 200V
Average Rectified Current 8A
Number of Phases 1
Reverse Recovery Time 25 ns
Peak Reverse Current 5μA
Max Repetitive Reverse Voltage (Vrrm) 200V
Peak Non-Repetitive Surge Current 50A
Reverse Voltage 200V
Diode Configuration 1 Pair Common Cathode
Recovery Time 25 ns
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
