STTA3006PIRG
RoHS
RoHS compliant
RoHS compliantPackage DOP3I-2 Insulated (Straight Leads)
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY GP 600V 30A DOP3I
PDF
/
Inventory: 1796
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
Recovery Time 65 ns
Diode Configuration 2 Independent
Reverse Voltage 600V
Peak Non-Repetitive Surge Current 230A
Peak Reverse Current 150μA
Reverse Recovery Time 65 ns
Average Rectified Current 30A
Max Reverse Voltage (DC) 600V
Forward Voltage 1.75V
Current - Average Rectified (Io) 30A
Voltage - DC Reverse (Vr) (Max) 600V
Max Surge Current 230A
Operating Temperature - Junction 150°C Max
Voltage - Forward (Vf) (Max) @ If 1.75V @ 30A
Power Dissipation 60W
Current - Reverse Leakage @ Vr 150μA @ 480V
Diode Type Standard
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Single
Base Part Number STTA300
Current Rating 30A
Voltage - Rated DC 600V
Min Operating Temperature -65°C
Max Operating Temperature 150°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series TURBOSWITCH?
Packaging Tube
Physical
Supplier Device Package DOP3I
Number of Pins 2
Package / Case DOP3I-2 Insulated (Straight Leads)
Mounting Type Through Hole
Mount Radial, Through Hole
