STPSC10H12CWL
RoHS
/
Package TO-247-3
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY SCHOTTKY 1200V TO247
PDF
/
Buying Options
Total Price: USD $6.38
Unit Price: USD $6.38
≥1 USD $6.38
≥10 USD $5.4692
≥100 USD $4.557696
≥500 USD $4.021468
≥1000 USD $3.619317
≥3000 USD $3.391432
Inventory: 631
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Reverse Current-Max 30μA
Diode Configuration 1 Pair Common Cathode
Rep Pk Reverse Voltage-Max 1200V
Reverse Recovery Time 0ns
Number of Phases 1
Current - Average Rectified (Io) 19A
Voltage - DC Reverse (Vr) (Max) 1200V
Application HIGH VOLTAGE POWER
Output Current-Max 19A
Operating Temperature - Junction -40°C~175°C
Forward Current 10A
Voltage - Forward (Vf) (Max) @ If 1.5V @ 5A
Current - Reverse Leakage @ Vr 30μA @ 1200V
Diode Type Silicon Carbide Schottky
Speed No Recovery Time > 500mA (Io)
Number of Elements 2
Operating Temperature (Max) 175°C
JESD-30 Code R-PSFM-T3
Base Part Number STPSC10
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series ECOPACK?
Packaging Tube
Physical
Surface Mount NO
Package / Case TO-247-3
Mounting Type Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 14 Weeks
