STPS40SM120CTN
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
STMICROELECTRONICS STPS40SM120CTN DIODE, SCHOTTKY, 2X20A, 120V ,TO-220AB
PDF
/
Buying Options
Total Price: USD $2.59
Unit Price: USD $2.5872
≥1 USD $2.5872
≥10 USD $2.053216
≥100 USD $1.759824
≥500 USD $1.564288
≥1000 USD $1.339422
Inventory: 1067
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Technical
Natural Thermal Resistance 0.93 °C/W
Max Forward Surge Current (Ifsm) 210A
Diode Configuration 1 Pair Common Cathode
Peak Non-Repetitive Surge Current 210A
Max Repetitive Reverse Voltage (Vrrm) 120V
Peak Reverse Current 275μA
Number of Phases 1
Average Rectified Current 30A
Max Reverse Voltage (DC) 120V
Forward Voltage 830mV
Current - Average Rectified (Io) 20A
Application EFFICIENCY
Operating Temperature - Junction 150°C Max
Forward Current 40A
Voltage - Forward (Vf) (Max) @ If 830mV @ 20A
Current - Reverse Leakage @ Vr 275μA @ 120V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Common Cathode
Number of Elements 2
Base Part Number STPS40
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Min Operating Temperature -65°C
Max Operating Temperature 150°C
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Packaging Tube
Physical
Diode Element Material SILICON
Number of Pins 3
Package / Case TO-220-3
Mounting Type Through Hole
Mount Through Hole
