STPS40SM100CG-TR
RoHS
RoHS compliant
RoHS compliantPackage TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY SCHOTTKY 100V D2PAK
PDF
/
Buying Options
Total Price: USD $3.34
Unit Price: USD $3.344
≥1 USD $3.344
≥10 USD $2.80456
Inventory: 113
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Number of Pins 3
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Max Operating Temperature 150°C
Min Operating Temperature -65°C
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Terminal Position SINGLE
Terminal Form GULL WING
Base Part Number STPS40
Pin Count 3
JESD-30 Code R-PSSO-G2
Number of Elements 2
Element Configuration Common Anode
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 45μA @ 100V
Voltage - Forward (Vf) (Max) @ If 810mV @ 20A
Forward Current 40A
Max Reverse Leakage Current 45μA
Operating Temperature - Junction 150°C Max
Max Surge Current 530A
Application EFFICIENCY
Forward Voltage 810mV
Max Reverse Voltage (DC) 100V
Average Rectified Current 20A
Number of Phases 1
Peak Reverse Current 45μA
Max Repetitive Reverse Voltage (Vrrm) 100V
Peak Non-Repetitive Surge Current 530A
Diode Configuration 1 Pair Common Cathode
Max Forward Surge Current (Ifsm) 530A
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
