STPS40L45CW
RoHS
RoHS compliant
RoHS compliantPackage TO-247-3
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY SCHOTTKY 45V TO247-3
PDF
/
Buying Options
Total Price: USD $2.17
Unit Price: USD $2.1736
≥1 USD $2.1736
≥10 USD $1.74357
≥100 USD $1.43455
≥500 USD $1.213828
≥1000 USD $1.029926
≥3000 USD $0.978428
Inventory: 1178
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 11 Weeks
Physical
Mount Radial, Through Hole
Mounting Type Through Hole
Package / Case TO-247-3
Diode Element Material SILICON
Technical
Packaging Tube
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Tin (Sn)
Max Operating Temperature 150°C
Min Operating Temperature -65°C
Additional Feature FREE WHEELING DIODE
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Voltage - Rated DC 45V
Terminal Position SINGLE
Current Rating 40A
Base Part Number STPS40
Pin Count 3
JESD-30 Code R-PSFM-T3
Number of Elements 2
Element Configuration Common Cathode
Speed Fast Recovery =< 500ns, > 200mA (Io)
Max Forward Surge Current (Ifsm) 230A
Diode Configuration 1 Pair Common Cathode
Peak Non-Repetitive Surge Current 230A
JEDEC-95 Code TO-247AC
Max Repetitive Reverse Voltage (Vrrm) 45V
Peak Reverse Current 600μA
Number of Phases 1
Average Rectified Current 20A
Max Reverse Voltage (DC) 45V
Forward Voltage 690mV
Application POWER
Operating Temperature - Junction 150°C Max
Forward Current 40A
Voltage - Forward (Vf) (Max) @ If 530mV @ 20A
Current - Reverse Leakage @ Vr 600μA @ 45V
Diode Type Schottky
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
