STPS4045CP
RoHS
RoHS compliant
RoHS compliantPackage TO-218-3
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY SCHOTTKY 45V SOT93
PDF
/
Inventory: 8620
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Radial, Through Hole
Mounting Type Through Hole
Package / Case TO-218-3
Diode Element Material SILICON
Technical
Packaging Tube
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Additional Feature FREE WHEELING DIODE
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Voltage - Rated DC 45V
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code not_compliant
Current Rating 40A
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number STPS404
Pin Count 3
JESD-30 Code R-PSFM-T3
Qualification Status Not Qualified
Operating Temperature (Max) 150°C
Number of Elements 2
Element Configuration Common Cathode
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 200μA @ 45V
Voltage - Forward (Vf) (Max) @ If 760mV @ 20A
Max Reverse Leakage Current 200μA
Operating Temperature - Junction 175°C Max
Max Surge Current 220A
Application POWER
Max Reverse Voltage (DC) 45V
Average Rectified Current 20A
Number of Phases 1
JEDEC-95 Code TO-218AC
Diode Configuration 1 Pair Common Cathode
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
