STPS40170CW
RoHS
RoHS compliant
RoHS compliantPackage TO-247-3
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY SCHOTTKY 170V TO247
PDF
/
Buying Options
Total Price: USD $19.27
Unit Price: USD $19.27455
≥1 USD $19.27455
≥10 USD $15.8156
≥100 USD $15.3216
≥500 USD $14.82665
≥1000 USD $14.33265
≥1000 USD $12.8497
Inventory: 1162
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Radial, Through Hole
Mounting Type Through Hole
Package / Case TO-247-3
Diode Element Material SILICON
Technical
Packaging Tube
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Tin (Sn)
Max Operating Temperature 175°C
Min Operating Temperature -65°C
Additional Feature LOW LEAKAGE CURRENT
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Voltage - Rated DC 170V
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code not_compliant
Current Rating 40A
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number STPS401
Pin Count 3
JESD-30 Code R-PSFM-T3
Qualification Status Not Qualified
Number of Elements 2
Element Configuration Common Cathode
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 30μA @ 170V
Voltage - Forward (Vf) (Max) @ If 920mV @ 20A
Max Reverse Leakage Current 30μA
Operating Temperature - Junction 175°C Max
Max Surge Current 250A
Application HIGH VOLTAGE POWER
Forward Voltage 1V
Max Reverse Voltage (DC) 170V
Average Rectified Current 20A
Number of Phases 1
JEDEC-95 Code TO-247AC
Peak Non-Repetitive Surge Current 250A
Diode Configuration 1 Pair Common Cathode
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
