STPS40120CT
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY SCHOTTKY 120V TO220
PDF
/
Buying Options
Total Price: USD $5.37
Unit Price: USD $5.37035
≥1 USD $5.37035
≥10 USD $4.4061
≥100 USD $4.26835
≥500 USD $4.1306
≥1000 USD $3.99285
Inventory: 1736
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Diode Configuration 1 Pair Common Cathode
Peak Non-Repetitive Surge Current 200A
JEDEC-95 Code TO-220AB
Max Repetitive Reverse Voltage (Vrrm) 120V
Peak Reverse Current 25μA
Number of Phases 1
Average Rectified Current 20A
Max Reverse Voltage (DC) 120V
Forward Voltage 1V
Application POWER
Max Surge Current 200A
Operating Temperature - Junction 175°C Max
Max Reverse Leakage Current 25μA
Forward Current 20A
Voltage - Forward (Vf) (Max) @ If 900mV @ 20A
Current - Reverse Leakage @ Vr 25μA @ 120V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Common Cathode
Number of Elements 2
Pin Count 3
Base Part Number STPS401
Current Rating 40A
Terminal Position SINGLE
Voltage - Rated DC 120V
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
Min Operating Temperature -65°C
Max Operating Temperature 175°C
Terminal Finish Tin (Sn)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Packaging Tube
Physical
Diode Element Material SILICON
Number of Pins 3
Package / Case TO-220-3
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 11 Weeks
Alternative Model
