STPS30L60CTN
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
Diode Schottky 60V 30A 3-Pin(3+Tab) TO-220AB Tube
PDF
/
Buying Options
Total Price: USD $2.44
Unit Price: USD $2.4376
≥1 USD $2.4376
≥10 USD $1.959056
≥100 USD $1.611808
≥500 USD $1.363859
Inventory: 801
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-3
Number of Pins 3
Diode Element Material SILICON
Technical
Packaging Tube
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 3
ECCN Code EAR99
Max Operating Temperature 150°C
Min Operating Temperature -65°C
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number STPS30L60
Pin Count 3
Number of Elements 2
Element Configuration Common Cathode
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 480μA @ 60V
Voltage - Forward (Vf) (Max) @ If 600mV @ 15A
Forward Current 30A
Operating Temperature - Junction 150°C Max
Application POWER
Max Reverse Voltage (DC) 60V
Average Rectified Current 15A
Number of Phases 1
Peak Reverse Current 480μA
Max Repetitive Reverse Voltage (Vrrm) 60V
JEDEC-95 Code TO-220AB
Peak Non-Repetitive Surge Current 230A
Diode Configuration 1 Pair Common Cathode
Natural Thermal Resistance 0.8 °C/W
Compliance
RoHS Status ROHS3 Compliant
