STPS30L45CW
RoHS
RoHS compliant
RoHS compliantPackage TO-247-3
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY SCHOTTKY 45V TO247-3
PDF
/
Buying Options
Total Price: USD $1.6
Unit Price: USD $1.6016
≥1 USD $1.6016
≥10 USD $1.28979
≥100 USD $1.06121
≥500 USD $0.897943
≥1000 USD $0.761895
≥3000 USD $0.7238
Inventory: 1181
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-247-3
Diode Element Material SILICON
Technical
Packaging Tube
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Tin (Sn)
Max Operating Temperature 150°C
Min Operating Temperature -65°C
Additional Feature FREE WHEELING DIODE
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Voltage - Rated DC 45V
Terminal Position SINGLE
Current Rating 30A
Base Part Number STPS30L45
Pin Count 3
JESD-30 Code R-PSFM-T3
Number of Elements 2
Element Configuration Common Cathode
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 400μA @ 45V
Voltage - Forward (Vf) (Max) @ If 550mV @ 15A
Forward Current 30A
Max Reverse Leakage Current 400μA
Operating Temperature - Junction 150°C Max
Max Surge Current 220A
Application POWER
Forward Voltage 740mV
Max Reverse Voltage (DC) 45V
Average Rectified Current 15A
Number of Phases 1
Peak Reverse Current 400μA
Max Repetitive Reverse Voltage (Vrrm) 45V
Peak Non-Repetitive Surge Current 220A
Diode Configuration 1 Pair Common Cathode
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
