STPS30L45CFP
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3 Full Pack
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY SCHOTTKY 45V TO220FP
PDF
/
Buying Options
Total Price: USD $0.72
Unit Price: USD $0.7216
≥1 USD $0.7216
≥10 USD $0.57992
≥100 USD $0.459624
≥500 USD $0.389576
≥1000 USD $0.385334
Inventory: 1599
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-3 Full Pack
Number of Pins 3
Diode Element Material SILICON
Technical
Packaging Tube
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Max Operating Temperature 150°C
Min Operating Temperature -65°C
Additional Feature FREE WHEELING DIODE
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Voltage - Rated DC 45V
Terminal Position SINGLE
Current Rating 30A
Base Part Number STPS30L45
Pin Count 3
Number of Elements 2
Element Configuration Common Cathode
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 400μA @ 45V
Voltage - Forward (Vf) (Max) @ If 550mV @ 15A
Case Connection ISOLATED
Forward Current 30A
Operating Temperature - Junction 150°C Max
Application POWER
Forward Voltage 740mV
Max Reverse Voltage (DC) 45V
Average Rectified Current 15A
Number of Phases 1
Peak Reverse Current 400μA
Max Repetitive Reverse Voltage (Vrrm) 45V
JEDEC-95 Code TO-220AB
Peak Non-Repetitive Surge Current 220A
Diode Configuration 1 Pair Common Cathode
Max Forward Surge Current (Ifsm) 220A
Dimensions
Height 9.3mm
Length 10.4mm
Width 4.6mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
