STPS20M80CFP
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3 Full Pack
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY SCHOTTKY 80V TO220FP
PDF
/
Buying Options
Total Price: USD $5.46
Unit Price: USD $5.45585
≥1 USD $5.45585
≥10 USD $4.4764
≥100 USD $4.33675
≥500 USD $4.1971
≥1000 USD $4.05745
Inventory: 1749
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-3 Full Pack
Number of Pins 3
Diode Element Material SILICON
Technical
Packaging Tube
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Max Operating Temperature 175°C
Min Operating Temperature -65°C
Additional Feature LOW LEAKAGE CURRENT
Subcategory Rectifier Diodes
Max Power Dissipation 6.7kW
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number STPS20
Pin Count 3
Number of Elements 2
Element Configuration Common Cathode
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 30μA @ 80V
Voltage - Forward (Vf) (Max) @ If 740mV @ 10A
Case Connection ISOLATED
Forward Current 20A
Max Reverse Leakage Current 30μA
Operating Temperature - Junction 175°C Max
Max Surge Current 220A
Application EFFICIENCY
Forward Voltage 905mV
Max Reverse Voltage (DC) 80V
Average Rectified Current 10A
Number of Phases 1
Peak Reverse Current 30μA
Max Repetitive Reverse Voltage (Vrrm) 80V
JEDEC-95 Code TO-220AB
Peak Non-Repetitive Surge Current 220A
Diode Configuration 1 Pair Common Cathode
Max Forward Surge Current (Ifsm) 220A
Dimensions
Height 16.4mm
Length 10.7mm
Width 4.9mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
