STPS20L25CT
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY SCHOTTKY 25V TO220AB
PDF
/
Buying Options
Total Price: USD $0.8
Unit Price: USD $0.8018
≥1 USD $0.8018
≥10 USD $0.65835
≥100 USD $0.63745
≥500 USD $0.6175
≥1000 USD $0.5966
Inventory: 18004
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-3
Number of Pins 3
Diode Element Material SILICON
Technical
Packaging Tube
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Max Operating Temperature 150°C
Min Operating Temperature -65°C
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Voltage - Rated DC 25V
Terminal Position SINGLE
Current Rating 20A
Base Part Number STPS20
Pin Count 3
Number of Elements 2
Element Configuration Common Cathode
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 800μA @ 25V
Voltage - Forward (Vf) (Max) @ If 460mV @ 10A
Forward Current 10A
Max Reverse Leakage Current 800μA
Operating Temperature - Junction 150°C Max
Max Surge Current 220A
Application GENERAL PURPOSE
Forward Voltage 350mV
Max Reverse Voltage (DC) 25V
Average Rectified Current 10A
Number of Phases 1
Peak Reverse Current 800μA
Max Repetitive Reverse Voltage (Vrrm) 25V
JEDEC-95 Code TO-220AB
Peak Non-Repetitive Surge Current 220A
Diode Configuration 1 Pair Common Cathode
Max Forward Surge Current (Ifsm) 220A
Dimensions
Height 15.75mm
Length 10.4mm
Width 4.6mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
