STPS20H100CT
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY SCHOTTKY 100V TO220
PDF
/
Buying Options
Total Price: USD $0.53
Unit Price: USD $0.528
≥1 USD $0.528
≥10 USD $0.424688
≥100 USD $0.336512
≥500 USD $0.285261
≥1000 USD $0.282146
Inventory: 9894
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 4.6mm
Length 10.4mm
Height 9.15mm
Technical
Max Forward Surge Current (Ifsm) 250A
Diode Configuration 1 Pair Common Cathode
Peak Non-Repetitive Surge Current 250A
RMS Current (Irms) 30A
JEDEC-95 Code TO-220AB
Max Repetitive Reverse Voltage (Vrrm) 100V
Peak Reverse Current 4.5μA
Number of Phases 1
Average Rectified Current 10A
Max Reverse Voltage (DC) 100V
Forward Voltage 880mV
Application HIGH VOLTAGE POWER
Max Surge Current 250A
Operating Temperature - Junction 175°C Max
Max Reverse Leakage Current 4.5μA
Forward Current 20A
Voltage - Forward (Vf) (Max) @ If 770mV @ 10A
Current - Reverse Leakage @ Vr 4.5μA @ 100V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Common Cathode
Number of Elements 2
Pin Count 3
Base Part Number STPS20
Current Rating 20A
Terminal Position SINGLE
Voltage - Rated DC 100V
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
Additional Feature AVALANCHE RATED
Min Operating Temperature -65°C
Max Operating Temperature 175°C
Terminal Finish Matte Tin (Sn) - annealed
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Packaging Tube
Physical
Diode Element Material SILICON
Weight 4.535924g
Number of Pins 3
Package / Case TO-220-3
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 months ago)
Factory Lead Time 11 Weeks
