STPS2045CG-TR
RoHS
RoHS compliant
RoHS compliantPackage TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY SCHOTTKY 45V D2PAK
PDF
/
Buying Options
Total Price: USD $0.86
Unit Price: USD $0.8624
≥1 USD $0.8624
≥10 USD $0.7084
≥100 USD $0.551144
≥500 USD $0.467192
Inventory: 3993
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 9.35mm
Length 10.4mm
Height 4.6mm
Technical
Max Forward Surge Current (Ifsm) 180A
Diode Configuration 1 Pair Common Cathode
Peak Non-Repetitive Surge Current 180A
Max Repetitive Reverse Voltage (Vrrm) 45V
Peak Reverse Current 100μA
Number of Phases 1
Average Rectified Current 10A
Max Reverse Voltage (DC) 45V
Forward Voltage 840mV
Application POWER
Max Surge Current 180A
Operating Temperature - Junction 175°C Max
Max Reverse Leakage Current 100μA
Forward Current 20A
Voltage - Forward (Vf) (Max) @ If 570mV @ 10A
Current - Reverse Leakage @ Vr 100μA @ 45V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Common Cathode
Number of Elements 2
JESD-30 Code R-PSSO-G2
Pin Count 3
Base Part Number STPS2045
Time@Peak Reflow Temperature-Max (s) 30
Current Rating 20A
Peak Reflow Temperature (Cel) 245
Terminal Form GULL WING
Terminal Position SINGLE
Voltage - Rated DC 45V
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
Additional Feature FREE WHEELING DIODE
Min Operating Temperature -65°C
Max Operating Temperature 175°C
Terminal Finish Matte Tin (Sn) - annealed
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Number of Pins 3
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 11 Weeks
