STPS20200CT
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY SCHOTTKY 200V TO220
PDF
/
Buying Options
Total Price: USD $1.43
Unit Price: USD $1.4344
≥1 USD $1.4344
≥10 USD $1.152976
≥100 USD $0.913616
≥500 USD $0.774418
≥1000 USD $0.630846
≥3000 USD $0.593868
Inventory: 841
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 weeks ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-3
Number of Pins 3
Diode Element Material SILICON
Technical
Packaging Tube
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Max Operating Temperature 175°C
Min Operating Temperature -40°C
Terminal Position SINGLE
Base Part Number STPS20200
Number of Elements 2
Element Configuration Common Cathode
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 15μA @ 200V
Voltage - Forward (Vf) (Max) @ If 860mV @ 10A
Forward Current 20A
Operating Temperature - Junction -40°C~175°C
Application FAST RECOVERY POWER
Forward Voltage 640mV
Max Reverse Voltage (DC) 200V
Average Rectified Current 10A
Number of Phases 1
Peak Reverse Current 15μA
Max Repetitive Reverse Voltage (Vrrm) 200V
JEDEC-95 Code TO-220AB
Peak Non-Repetitive Surge Current 180A
Diode Configuration 1 Pair Common Cathode
Max Forward Surge Current (Ifsm) 180A
Dimensions
Height 15.75mm
Length 10.4mm
Width 4.6mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
