STPS20200CFP
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3 Full Pack
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY SCHOTTKY 200V TO220F
PDF
/
Buying Options
Total Price: USD $1.45
Unit Price: USD $1.452
≥1 USD $1.452
≥10 USD $1.164416
≥100 USD $0.922768
≥500 USD $0.782179
≥1000 USD $0.637164
≥3000 USD $0.599817
Inventory: 938
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 4.6mm
Length 10.4mm
Height 16.4mm
Technical
Max Forward Surge Current (Ifsm) 180A
Diode Configuration 1 Pair Common Cathode
Peak Non-Repetitive Surge Current 180A
JEDEC-95 Code TO-220AB
Max Repetitive Reverse Voltage (Vrrm) 200V
Peak Reverse Current 15μA
Number of Phases 1
Average Rectified Current 10A
Max Reverse Voltage (DC) 200V
Forward Voltage 640mV
Application FAST RECOVERY POWER
Max Surge Current 180A
Operating Temperature - Junction -40°C~175°C
Max Reverse Leakage Current 7mA
Forward Current 20A
Case Connection ISOLATED
Voltage - Forward (Vf) (Max) @ If 860mV @ 10A
Current - Reverse Leakage @ Vr 15μA @ 200V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Common Cathode
Number of Elements 2
Base Part Number STPS20200
Terminal Position SINGLE
Min Operating Temperature -40°C
Max Operating Temperature 175°C
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Packaging Tube
Physical
Diode Element Material SILICON
Number of Pins 3
Package / Case TO-220-3 Full Pack
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 weeks ago)
Factory Lead Time 15 Weeks
