STPS20170CG-TR
RoHS
RoHS compliant
RoHS compliantPackage TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY SCHOTTKY 170V D2PAK
PDF
/
Buying Options
Total Price: USD $1.06
Unit Price: USD $1.0648
≥1 USD $1.0648
≥10 USD $0.87032
≥100 USD $0.67716
≥500 USD $0.573971
Inventory: 584
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Technical
Max Forward Surge Current (Ifsm) 180A
Diode Configuration 1 Pair Common Cathode
Peak Non-Repetitive Surge Current 180A
Max Repetitive Reverse Voltage (Vrrm) 170V
Peak Reverse Current 15μA
Number of Phases 1
Average Rectified Current 10A
Max Reverse Voltage (DC) 170V
Forward Voltage 990mV
Application HIGH VOLTAGE POWER
Max Surge Current 180A
Operating Temperature - Junction 175°C Max
Max Reverse Leakage Current 15μA
Forward Current 20A
Voltage - Forward (Vf) (Max) @ If 900mV @ 10A
Current - Reverse Leakage @ Vr 15μA @ 170V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Common Cathode
Number of Elements 2
Pin Count 3
Base Part Number STPS20170
Current Rating 20A
Terminal Form GULL WING
Terminal Position SINGLE
Voltage - Rated DC 170V
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
Min Operating Temperature -65°C
Max Operating Temperature 175°C
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 months ago)
Factory Lead Time 11 Weeks
