STPS20120CTN
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
Diode Schottky 120V 20A 3-Pin(3+Tab) TO-220AB Tube
PDF
/
Buying Options
Total Price: USD $1.58
Unit Price: USD $1.5752
≥1 USD $1.5752
≥10 USD $1.263856
≥100 USD $1.039896
≥500 USD $0.879912
≥1000 USD $0.746592
Inventory: 1004
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Natural Thermal Resistance 1.8 °C/W
Diode Configuration 1 Pair Common Cathode
Peak Non-Repetitive Surge Current 150A
JEDEC-95 Code TO-220AB
Max Repetitive Reverse Voltage (Vrrm) 120V
Peak Reverse Current 10μA
Number of Phases 1
Average Rectified Current 10A
Max Reverse Voltage (DC) 120V
Application POWER
Operating Temperature - Junction 175°C Max
Forward Current 20A
Voltage - Forward (Vf) (Max) @ If 920mV @ 10A
Current - Reverse Leakage @ Vr 10μA @ 120V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Common Cathode
Number of Elements 2
Pin Count 3
Base Part Number STPS20120
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Additional Feature LOW LEAKAGE CURRENT
Min Operating Temperature -65°C
Max Operating Temperature 175°C
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Packaging Tube
Physical
Diode Element Material SILICON
Number of Pins 3
Package / Case TO-220-3
Mounting Type Through Hole
Mount Through Hole
