STPS200170TV1Y
RoHS
RoHS compliant
RoHS compliantPackage ISOTOP
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE MODULE 170V 100A ISOTOP
PDF
/
Buying Options
Total Price: USD $22.53
Unit Price: USD $22.528
≥1 USD $22.528
≥10 USD $20.01824
≥100 USD $17.50892
≥500 USD $14.940939
Inventory: 462
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Diode Configuration 2 Independent
Peak Non-Repetitive Surge Current 700A
Max Repetitive Reverse Voltage (Vrrm) 170V
Peak Reverse Current 200μA
Number of Phases 1
Average Rectified Current 100A
Max Reverse Voltage (DC) 170V
Forward Voltage 1.01V
Application HIGH VOLTAGE
Max Surge Current 700A
Operating Temperature - Junction -55°C~150°C
Max Reverse Leakage Current 100mA
Forward Current 200A
Case Connection ISOLATED
Voltage - Forward (Vf) (Max) @ If 850mV @ 100A
Current - Reverse Leakage @ Vr 200μA @ 170V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Single
Number of Elements 2
Pin Count 4
Base Part Number STPS200170
Terminal Form UNSPECIFIED
Terminal Position UPPER
Subcategory Other Diodes
Min Operating Temperature -55°C
Max Operating Temperature 150°C
Terminal Finish Nickel (Ni)
ECCN Code EAR99
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Q Automotive
Packaging Tube
Physical
Diode Element Material SILICON
Number of Pins 4
Package / Case ISOTOP
Mounting Type Chassis Mount
Mount Chassis Mount, Screw
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Factory Lead Time 31 Weeks
