STPS15SM80CG-TR
RoHS
RoHS compliant
RoHS compliantPackage TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY SCHOTTKY 80V D2PAK
PDF
/
Buying Options
Total Price: USD $1.71
Unit Price: USD $1.705285
≥1 USD $1.705285
≥10 USD $1.608764
≥100 USD $1.517698
≥500 USD $1.431793
≥1000 USD $1.350748
Inventory: 1000
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 9.35mm
Length 10.4mm
Height 4.6mm
Technical
Max Forward Surge Current (Ifsm) 150A
Diode Configuration 1 Pair Common Cathode
Peak Non-Repetitive Surge Current 150A
Max Repetitive Reverse Voltage (Vrrm) 80V
Peak Reverse Current 20μA
Number of Phases 1
Average Rectified Current 7.5A
Max Reverse Voltage (DC) 80V
Forward Voltage 955mV
Application EFFICIENCY
Max Surge Current 150A
Operating Temperature - Junction 175°C Max
Max Reverse Leakage Current 20μA
Forward Current 15A
Voltage - Forward (Vf) (Max) @ If 780mV @ 7.5A
Current - Reverse Leakage @ Vr 20μA @ 80V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Common Cathode
Number of Elements 2
JESD-30 Code R-PSSO-G2
Pin Count 3
Base Part Number STPS15
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Peak Reflow Temperature (Cel) 245
Terminal Form GULL WING
Terminal Position SINGLE
Max Power Dissipation 4kW
Subcategory Rectifier Diodes
Additional Feature LOW LEAKAGE CURRENT
Min Operating Temperature -65°C
Max Operating Temperature 175°C
Terminal Finish Matte Tin (Sn) - annealed
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Number of Pins 3
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Mounting Type Surface Mount
Mount Surface Mount
