STPS15M80CR
RoHS
RoHS compliant
RoHS compliantPackage TO-262-3 Long Leads, I2Pak, TO-262AA
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY SCHOTTKY 80V I2PAK
PDF
/
Buying Options
Total Price: USD $1.62
Unit Price: USD $1.623979
≥1 USD $1.623979
≥10 USD $1.532062
≥100 USD $1.445333
≥500 USD $1.363529
≥1000 USD $1.286342
Inventory: 4810
Minimum: 1
-
+
Technical Details
Technical
Additional Feature LOW LEAKAGE CURRENT
Min Operating Temperature -65°C
Max Operating Temperature 175°C
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Packaging Tube
Max Forward Surge Current (Ifsm) 220A
Diode Configuration 1 Pair Common Cathode
Peak Non-Repetitive Surge Current 220A
Max Repetitive Reverse Voltage (Vrrm) 80V
Peak Reverse Current 25μA
Number of Phases 1
Average Rectified Current 7.5A
Max Reverse Voltage (DC) 80V
Forward Voltage 870mV
Application EFFICIENCY
Max Surge Current 220A
Operating Temperature - Junction 175°C Max
Max Reverse Leakage Current 25μA
Forward Current 15A
Voltage - Forward (Vf) (Max) @ If 725mV @ 7.5A
Current - Reverse Leakage @ Vr 25μA @ 80V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Common Cathode
Number of Elements 2
Pin Count 3
Base Part Number STPS15
Terminal Position SINGLE
Subcategory Rectifier Diodes
Physical
Diode Element Material SILICON
Number of Pins 3
Package / Case TO-262-3 Long Leads, I2Pak, TO-262AA
Mounting Type Through Hole
Mount Through Hole
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 4.6mm
Length 10.4mm
Height 10.75mm
