STPS10120CFP
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3 Full Pack
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY SCHOTTKY 120V TO220F
PDF
/
Inventory: 7786
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-3 Full Pack
Number of Pins 3
Diode Element Material SILICON
Technical
Packaging Tube
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 3
ECCN Code EAR99
Max Operating Temperature 175°C
Min Operating Temperature -65°C
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number STPS10120
Pin Count 3
Qualification Status Not Qualified
Number of Elements 2
Element Configuration Common Cathode
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 6μA @ 120V
Voltage - Forward (Vf) (Max) @ If 850mV @ 5A
Case Connection ISOLATED
Max Reverse Leakage Current 6μA
Operating Temperature - Junction 175°C Max
Max Surge Current 120A
Output Current-Max 5A
Application POWER
Forward Voltage 960mV
Max Reverse Voltage (DC) 120V
Average Rectified Current 5A
Number of Phases 1
Peak Reverse Current 6μA
Max Repetitive Reverse Voltage (Vrrm) 120V
JEDEC-95 Code TO-220AB
Peak Non-Repetitive Surge Current 120A
Diode Configuration 1 Pair Common Cathode
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
