STPR1620CG-TR
RoHS
RoHS compliant
RoHS compliantPackage TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY GP 200V 8A D2PAK
PDF
/
Buying Options
Total Price: USD $0.4
Unit Price: USD $0.4028
≥1 USD $0.4028
≥10 USD $0.3306
≥100 USD $0.32015
≥500 USD $0.31065
≥1000 USD $0.3002
Inventory: 8483
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
Recovery Time 30 ns
Diode Configuration 1 Pair Common Cathode
Reverse Voltage 200V
Peak Reverse Current 50μA
Reverse Recovery Time 30 ns
Number of Phases 1
Average Rectified Current 8A
Max Reverse Voltage (DC) 200V
Application ULTRA FAST RECOVERY
Output Current-Max 8A
Max Surge Current 80A
Operating Temperature - Junction 150°C Max
Voltage - Forward (Vf) (Max) @ If 990mV @ 8A
Current - Reverse Leakage @ Vr 50μA @ 200V
Diode Type Standard
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Common Cathode
Number of Elements 2
Qualification Status Not Qualified
JESD-30 Code R-PSSO-G2
Pin Count 3
Base Part Number STPR1620
Time@Peak Reflow Temperature-Max (s) 30
Current Rating 16A
Reach Compliance Code not_compliant
Peak Reflow Temperature (Cel) 245
Terminal Form GULL WING
Terminal Position SINGLE
Voltage - Rated DC 200V
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
Additional Feature FREE WHEELING DIODE
Min Operating Temperature -65°C
Max Operating Temperature 150°C
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Mounting Type Surface Mount
Mount Surface Mount
