FERD40M45CT
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
Diode Schottky 45V 40A Automotive 3-Pin(3+Tab) TO-220AB Tube
PDF
/
Buying Options
Total Price: USD $1.03
Unit Price: USD $1.0296
≥1 USD $1.0296
≥10 USD $0.825088
≥100 USD $0.678832
≥500 USD $0.61292
Inventory: 916
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Lifecycle Status ACTIVE (Last Updated: 6 months ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-3
Number of Pins 3
Weight 2.299997g
Diode Element Material SILICON
Technical
Packaging Tube
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Max Operating Temperature 175°C
Min Operating Temperature -65°C
Terminal Position SINGLE
Base Part Number FERD40
Number of Elements 2
Element Configuration Common Cathode
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type FERD (Field Effect Rectifier Diode)
Current - Reverse Leakage @ Vr 650μA @ 45V
Voltage - Forward (Vf) (Max) @ If 500mV @ 20A
Forward Current 40A
Operating Temperature - Junction 175°C Max
Max Surge Current 275A
Application GENERAL PURPOSE
Forward Voltage 500mV
Max Reverse Voltage (DC) 45V
Average Rectified Current 20A
Number of Phases 1
Peak Reverse Current 25mA
Max Repetitive Reverse Voltage (Vrrm) 45V
JEDEC-95 Code TO-220AB
Peak Non-Repetitive Surge Current 275A
Diode Configuration 1 Pair Common Cathode
Reverse Voltage (DC) 45V
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
