FERD40M45CG-TR
RoHS
RoHS compliant
RoHS compliantPackage TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY 45V 20A D2PAK
PDF
/
Buying Options
Total Price: USD $1.73
Unit Price: USD $1.733319
≥1 USD $1.733319
≥10 USD $1.635211
≥100 USD $1.542645
≥500 USD $1.455334
≥1000 USD $1.372949
Inventory: 4701
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Reverse Voltage (DC) 45V
Diode Configuration 1 Pair Common Cathode
Peak Non-Repetitive Surge Current 275A
Max Repetitive Reverse Voltage (Vrrm) 45V
Peak Reverse Current 25mA
Number of Phases 1
Average Rectified Current 20A
Max Reverse Voltage (DC) 45V
Forward Voltage 500mV
Application GENERAL PURPOSE
Max Surge Current 275A
Operating Temperature - Junction 175°C Max
Forward Current 40A
Voltage - Forward (Vf) (Max) @ If 500mV @ 20A
Current - Reverse Leakage @ Vr 650μA @ 45V
Diode Type FERD (Field Effect Rectifier Diode)
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Common Cathode
Number of Elements 2
JESD-30 Code R-PSSO-G2
Base Part Number FERD40
Terminal Form GULL WING
Terminal Position SINGLE
Min Operating Temperature -65°C
Max Operating Temperature 175°C
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Weight 2.240009g
Number of Pins 3
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 months ago)
Factory Lead Time 15 Weeks
