FERD30M45CT
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
Schottky Diodes & Rectifiers ST advancd rectifier 45V 0.35Vf +175
PDF
/
Buying Options
Total Price: USD $0.95
Unit Price: USD $0.9504
≥1 USD $0.9504
≥10 USD $0.760496
≥100 USD $0.602624
≥500 USD $0.510805
≥1000 USD $0.505226
Inventory: 1102
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-3
Number of Pins 3
Diode Element Material SILICON
Technical
Packaging Tube
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Max Operating Temperature 175°C
Min Operating Temperature -65°C
Subcategory Rectifier Diodes
Terminal Position SINGLE
Base Part Number FERD30
Number of Elements 2
Element Configuration Common Cathode
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type FERD (Field Effect Rectifier Diode)
Current - Reverse Leakage @ Vr 600μA @ 45V
Voltage - Forward (Vf) (Max) @ If 470mV @ 15A
Forward Current 30A
Max Reverse Leakage Current 25mA
Operating Temperature - Junction 175°C Max
Max Surge Current 250A
Application GENERAL PURPOSE
Max Reverse Voltage (DC) 45V
Average Rectified Current 15A
Number of Phases 1
Max Repetitive Reverse Voltage (Vrrm) 45V
JEDEC-95 Code TO-220AB
Peak Non-Repetitive Surge Current 250A
Diode Configuration 1 Pair Common Cathode
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
