FERD30H60CG-TR
RoHS
RoHS compliant
RoHS compliantPackage TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY 60V 15A D2PAK
PDF
/
Buying Options
Total Price: USD $1.14
Unit Price: USD $1.139322
≥1 USD $1.139322
≥10 USD $1.074838
≥100 USD $1.014
≥500 USD $0.956597
≥1000 USD $0.902454
Inventory: 913
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mounting Type Surface Mount
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Surface Mount YES
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Terminal Position SINGLE
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number FERD30
JESD-30 Code R-PSSO-G2
Operating Temperature (Max) 175°C
Number of Elements 2
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type FERD (Field Effect Rectifier Diode)
Current - Reverse Leakage @ Vr 170μA @ 60V
Voltage - Forward (Vf) (Max) @ If 585mV @ 15A
Forward Current 30A
Operating Temperature - Junction 175°C Max
Application EFFICIENCY
Voltage - DC Reverse (Vr) (Max) 60V
Current - Average Rectified (Io) 15A
Number of Phases 1
Rep Pk Reverse Voltage-Max 60V
Diode Configuration 1 Pair Common Cathode
Reverse Current-Max 170μA
Compliance
RoHS Status ROHS3 Compliant
