BAT54-09P6FILM
RoHS
RoHS compliant
RoHS compliantPackage SOT-563, SOT-666
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY SCHOTTKY 40V SOT666
PDF
/
Inventory: 5169
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Voltage - Rated DC 40V
Terminal Position DUAL
Terminal Form FLAT
Peak Reflow Temperature (Cel) 260
Current Rating 300mA
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number BAT54
Pin Count 6
Qualification Status Not Qualified
Number of Elements 2
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 1μA @ 30V
Voltage - Forward (Vf) (Max) @ If 900mV @ 100mA
Max Reverse Leakage Current 1μA
Operating Temperature - Junction -40°C~150°C
Max Surge Current 1A
Output Current-Max 0.3A
Current - Average Rectified (Io) 300mA DC
Forward Voltage 900mV
Max Reverse Voltage (DC) 40V
Average Rectified Current 300mA
Reverse Recovery Time 5 ns
Peak Non-Repetitive Surge Current 1A
Diode Configuration 2 Independent
Recovery Time 5 ns
Reverse Test Voltage 30V
Subcategory Other Diodes
HTS Code 8541.10.00.70
Min Operating Temperature -40°C
Max Operating Temperature 150°C
Terminal Finish MATTE TIN
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Packaging Tape & Reel (TR)
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Diode Element Material SILICON
Number of Pins 6
Package / Case SOT-563, SOT-666
Mounting Type Surface Mount
Mount Surface Mount
