BAT46SWFILM
RoHS
RoHS compliant
RoHS compliantPackage SC-70, SOT-323
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY SCHOTTKY 100V SOT323
PDF
/
Inventory: 5035
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SC-70, SOT-323
Number of Pins 3
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish MATTE TIN
Max Operating Temperature 150°C
Min Operating Temperature -65°C
HTS Code 8541.10.00.70
Capacitance 10pF
Subcategory Rectifier Diodes
Voltage - Rated DC 100V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Current Rating 150mA
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number BAT46
Pin Count 3
Qualification Status Not Qualified
Number of Elements 2
Polarity Standard
Speed Small Signal =< 200mA (Io), Any Speed
Diode Type Schottky
Current - Reverse Leakage @ Vr 5μA @ 75V
Output Current 150mA
Voltage - Forward (Vf) (Max) @ If 450mV @ 10mA
Max Reverse Leakage Current 5μA
Operating Temperature - Junction 150°C Max
Max Surge Current 1A
Current - Average Rectified (Io) 150mA DC
Forward Voltage 1V
Max Reverse Voltage (DC) 100V
Average Rectified Current 150mA
Peak Reverse Current 20μA
Max Repetitive Reverse Voltage (Vrrm) 100V
Peak Non-Repetitive Surge Current 1A
Non-rep Pk Forward Current-Max 1A
Diode Configuration 1 Pair Series Connection
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
