RBR20NS60AFHTL
RoHS
RoHS compliant
RoHS compliantPackage TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY SCHOTT 60V 20A LPDS
PDF
/
Buying Options
Total Price: USD $1.24
Unit Price: USD $1.2408
≥1 USD $1.2408
≥10 USD $1.01728
≥100 USD $0.791384
≥500 USD $0.670789
Inventory: 910
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Reverse Current-Max 400μA
Diode Configuration 1 Pair Common Cathode
Non-rep Pk Forward Current-Max 100A
Rep Pk Reverse Voltage-Max 60V
Number of Phases 1
Current - Average Rectified (Io) 20A
Voltage - DC Reverse (Vr) (Max) 60V
Application GENERAL PURPOSE
Output Current-Max 10A
Operating Temperature - Junction 150°C Max
Voltage - Forward (Vf) (Max) @ If 640mV @ 10A
Current - Reverse Leakage @ Vr 400μA @ 60V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Number of Elements 2
Operating Temperature (Max) 150°C
JESD-30 Code R-PSSO-G2
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position SINGLE
Additional Feature HIGH RELIABILITY
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Automotive, AEC-Q101
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Surface Mount YES
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
