RB205T-90
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3 Full Pack
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY SCHOTTKY 90V TO220FN
PDF
/
Buying Options
Total Price: USD $0.81
Unit Price: USD $0.8056
≥1 USD $0.8056
≥10 USD $0.6612
≥100 USD $0.6403
≥500 USD $0.62035
≥1000 USD $0.59945
Inventory: 1785
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Diode Configuration 1 Pair Common Cathode
Peak Non-Repetitive Surge Current 100A
JEDEC-95 Code TO-220AB
Max Repetitive Reverse Voltage (Vrrm) 90V
Peak Reverse Current 300μA
Number of Phases 1
Average Rectified Current 7.5A
Max Reverse Voltage (DC) 90V
Application GENERAL PURPOSE
Max Surge Current 100A
Operating Temperature - Junction 150°C Max
Max Reverse Leakage Current 300μA
Forward Current 15A
Case Connection ISOLATED
Voltage - Forward (Vf) (Max) @ If 780mV @ 7.5A
Current - Reverse Leakage @ Vr 300μA @ 90V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Common Cathode
Number of Elements 2
Pin Count 3
Time@Peak Reflow Temperature-Max (s) 10
Peak Reflow Temperature (Cel) 260
Terminal Position SINGLE
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
Additional Feature HIGH RELIABILITY
Min Operating Temperature -40°C
Max Operating Temperature 150°C
Terminal Finish TIN SILVER COPPER
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Not For New Designs
Pbfree Code yes
JESD-609 Code e1
Published 2011
Packaging Bulk
Physical
Diode Element Material SILICON
Number of Pins 3
Package / Case TO-220-3 Full Pack
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 12 Weeks
