DAN202UMTL
RoHS
RoHS compliant
RoHS compliantPackage SC-85
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
Tape & Reel (TR) Surface Mount Standard 1Pair Common Cathode Diode Array 1.2V @ 100mA 100mA 200mW 4ns
PDF
/
Buying Options
Total Price: USD $0.25
Unit Price: USD $0.2464
≥1 USD $0.2464
≥10 USD $0.16808
≥100 USD $0.082104
≥500 USD $0.068499
≥1000 USD $0.047599
Inventory: 1265
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SC-85
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
Published 2011
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Max Operating Temperature 150°C
Min Operating Temperature -55°C
Additional Feature HIGH RELIABILITY
HTS Code 8541.10.00.70
Subcategory Rectifier Diodes
Max Power Dissipation 200mW
Terminal Position DUAL
Terminal Form FLAT
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number DAN202
JESD-30 Code R-PDSO-F3
Number of Elements 2
Element Configuration Common Cathode
Speed Small Signal =< 200mA (Io), Any Speed
Diode Type Standard
Current - Reverse Leakage @ Vr 100nA @ 70V
Voltage - Forward (Vf) (Max) @ If 1.2V @ 100mA
Forward Current 100mA
Max Reverse Leakage Current 100nA
Operating Temperature - Junction 150°C Max
Max Surge Current 4A
Output Current-Max 0.1A
Max Reverse Voltage (DC) 80V
Average Rectified Current 100mA
Reverse Recovery Time 4 ns
Max Repetitive Reverse Voltage (Vrrm) 80V
Diode Configuration 1 Pair Common Cathode
Recovery Time 4 ns
Compliance
RoHS Status ROHS3 Compliant
