FFA10U40DNTU
RoHS
RoHS compliant
RoHS compliantPackage TO-3P-3, SC-65-3
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
Tube Through Hole Standard 1Pair Common Cathode Diode Array 1.4V @ 10A 10A 50ns 400V
PDF
/
Buying Options
Total Price: USD $0.84
Unit Price: USD $0.8448
≥1 USD $0.8448
Inventory: 560
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Through Hole
Package / Case TO-3P-3, SC-65-3
Surface Mount NO
Diode Element Material SILICON
Technical
Packaging Tube
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Terminal Finish MATTE TIN
Additional Feature FREEWHEELING DIODE
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT APPLICABLE
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) NOT APPLICABLE
Pin Count 3
JESD-30 Code R-PSFM-T3
Qualification Status COMMERCIAL
Number of Elements 2
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 30μA @ 400V
Voltage - Forward (Vf) (Max) @ If 1.4V @ 10A
Operating Temperature - Junction -65°C~150°C
Output Current-Max 10A
Application ULTRA FAST SOFT RECOVERY POWER
Voltage - DC Reverse (Vr) (Max) 400V
Current - Average Rectified (Io) 10A
Number of Phases 1
Reverse Recovery Time 50ns
Rep Pk Reverse Voltage-Max 400V
Non-rep Pk Forward Current-Max 100A
Diode Configuration 1 Pair Common Cathode
Compliance
RoHS Status ROHS3 Compliant
