LQA20T200C
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY GP 200V 10A TO220AB
PDF
/
Buying Options
Total Price: USD $1.26
Unit Price: USD $1.2584
≥1 USD $1.2584
≥10 USD $1.0384
≥100 USD $0.880009
≥500 USD $0.7887
Inventory: 442
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Technical
Recovery Time 16 ns
Diode Configuration 1 Pair Common Cathode
Reverse Voltage 200V
Peak Non-Repetitive Surge Current 350A
JEDEC-95 Code TO-220AB
Max Repetitive Reverse Voltage (Vrrm) 200V
Peak Reverse Current 500μA
Reverse Recovery Time 16 ns
Number of Phases 1
Average Rectified Current 10A
Max Reverse Voltage (DC) 200V
Application EFFICIENCY
Max Surge Current 100A
Operating Temperature - Junction -55°C~150°C
Forward Current 20A
Voltage - Forward (Vf) (Max) @ If 1.15V @ 10A
Power Dissipation 41.7W
Current - Reverse Leakage @ Vr 500μA @ 200V
Diode Type Standard
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Common Cathode
Number of Elements 2
Terminal Position SINGLE
Technology SCHOTTKY
HTS Code 8541.10.00.80
Additional Feature FREE WHEELING DIODE, PD-CASE, SOFT FACTOR IS 0.41
Min Operating Temperature -55°C
Max Operating Temperature 150°C
Terminal Finish MATTE TIN
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series Qspeed?
Published 2013
Packaging Tube
Physical
Diode Element Material SILICON
Number of Pins 3
Package / Case TO-220-3
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 6 Weeks
