SB80W06T-H
RoHS
/
Package TO-251-3 Short Leads, IPak, TO-251AA
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
Bulk Through Hole Schottky 1Pair Common Cathode Diode Array 600mV @ 3A 4A 60V 150C
PDF
/
Buying Options
Total Price: USD $0.69
Unit Price: USD $0.690545
≥1 USD $0.690545
≥10 USD $0.651459
≥100 USD $0.614587
≥500 USD $0.579794
≥1000 USD $0.546981
Inventory: 1148
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Lifecycle Status LAST SHIPMENTS (Last Updated: 4 days ago)
Physical
Mounting Type Through Hole
Package / Case TO-251-3 Short Leads, IPak, TO-251AA
Surface Mount NO
Number of Pins 3
Diode Element Material SILICON
Technical
Packaging Bulk
Published 2013
JESD-609 Code e6
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Tin/Bismuth (Sn/Bi)
Max Operating Temperature 150°C
Min Operating Temperature -55°C
Additional Feature HIGH RELIABILITY
Subcategory Rectifier Diodes
Terminal Position SINGLE
Pin Count 3
Number of Elements 2
Element Configuration Common Cathode
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 100μA @ 30V
Voltage - Forward (Vf) (Max) @ If 600mV @ 3A
Forward Current 8A
Operating Temperature - Junction -55°C~150°C
Max Surge Current 40A
Output Current-Max 4A
Max Reverse Voltage (DC) 60V
Average Rectified Current 4A
Number of Phases 1
Max Repetitive Reverse Voltage (Vrrm) 60V
Peak Non-Repetitive Surge Current 40A
Diode Configuration 1 Pair Common Cathode
Max Forward Surge Current (Ifsm) 40A
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
