NTST30100CTH
RoHS
/
Package TO-220-3
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
TO-220-3 Through Hole Schottky 1Pair Common Cathode Diode Array 850mV @ 15A 15A 100V -40C~150C
PDF
/
Buying Options
Total Price: USD $0.58
Unit Price: USD $0.583496
≥1 USD $0.583496
≥10 USD $0.550467
≥100 USD $0.519309
≥500 USD $0.489909
≥1000 USD $0.462183
Inventory: 1143
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status LAST SHIPMENTS (Last Updated: 1 week ago)
Physical
Mounting Type Through Hole
Package / Case TO-220-3
Surface Mount NO
Number of Pins 3
Diode Element Material SILICON
Technical
Published 2013
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) Vendor Undefined
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Tin (Sn)
Additional Feature FREE WHEELING DIODE, LOW LEAKAGE CURRENT, LOW POWER LOSS
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 3
Operating Temperature (Max) 150°C
Number of Elements 2
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 500μA @ 100V
Voltage - Forward (Vf) (Max) @ If 850mV @ 15A
Operating Temperature - Junction -40°C~150°C
Output Current-Max 15A
Application EFFICIENCY
Voltage - DC Reverse (Vr) (Max) 100V
Current - Average Rectified (Io) 15A
Number of Phases 1
Rep Pk Reverse Voltage-Max 100V
JEDEC-95 Code TO-220AB
Non-rep Pk Forward Current-Max 160A
Diode Configuration 1 Pair Common Cathode
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
