NRVHP620LFST1G
RoHS
RoHS compliant
RoHS compliantPackage SOT-1023, 4-LFPAK
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE 200V 6A LFPAK4
PDF
/
Buying Options
Total Price: USD $1.39
Unit Price: USD $1.3904
≥1 USD $1.3904
≥10 USD $1.15456
≥100 USD $0.918896
≥500 USD $0.77755
≥1000 USD $0.659736
Inventory: 2984
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Reverse Test Voltage 200V
Reverse Current-Max 0.75μA
Diode Configuration 1 Independent
Non-rep Pk Forward Current-Max 120A
Rep Pk Reverse Voltage-Max 200V
Reverse Recovery Time 50ns
Number of Phases 1
Current - Average Rectified (Io) 6A
Voltage - DC Reverse (Vr) (Max) 200V
Application ULTRA FAST SOFT RECOVERY POWER
Output Current-Max 6A
Operating Temperature - Junction -55°C~175°C
Case Connection CATHODE
Voltage - Forward (Vf) (Max) @ If 950mV @ 6A
Current - Reverse Leakage @ Vr 500nA @ 200V
Diode Type Standard
Speed Fast Recovery =< 500ns, > 200mA (Io)
Number of Elements 1
Operating Temperature (Max) 175°C
JESD-30 Code R-PSSO-G4
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code compliant
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position SINGLE
Additional Feature FREE WHEEELING DIODE
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Automotive, AEC-Q101
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Surface Mount YES
Package / Case SOT-1023, 4-LFPAK
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 33 Weeks
