MSRD620CT
RoHS
/
Package TO-252-3, DPak (2 Leads + Tab), SC-63
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
SWITCHMODE? Tube Surface Mount Standard Diode Array 1.15V @ 3A 3A 55ns 200V
PDF
/
Buying Options
Total Price: USD $0.79
Unit Price: USD $0.78774
≥1 USD $0.78774
≥200 USD $0.305906
≥500 USD $0.295403
≥1000 USD $0.288838
Inventory: 1163
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Diode Element Material SILICON
Technical
Packaging Tube
Published 2007
Series SWITCHMODE?
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn80Pb20)
Max Operating Temperature 175°C
Min Operating Temperature -55°C
Additional Feature FREE WHEELING DIODE
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Voltage - Rated DC 200V
Technology SCHOTTKY
Terminal Position SINGLE
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 240
Reach Compliance Code not_compliant
Current Rating 6A
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number MSRD620CT
Pin Count 3
JESD-30 Code R-PSSO-G2
Qualification Status Not Qualified
Number of Elements 2
Element Configuration Common Cathode
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 5μA @ 200V
Voltage - Forward (Vf) (Max) @ If 1.15V @ 3A
Operating Temperature - Junction -55°C~175°C
Max Surge Current 50A
Output Current-Max 3A
Application ULTRA FAST SOFT RECOVERY POWER
Breakdown Voltage 200V
Max Reverse Voltage (DC) 200V
Average Rectified Current 3A
Number of Phases 1
Reverse Recovery Time 55 ns
Peak Reverse Current 5μA
Reverse Voltage 200V
Diode Configuration 1 Pair Common Cathode
Recovery Time 55 ns
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
